GPS Master Clock Solution with Wired Slave Clocks

Deployed to display accurate and uniform time in all the clocks of an industrial premises, all the slave clocks needs to be synchronized to UTC. The UTC is obtained using the GPS Master Clock. All the slave clocks are connected to the master clock using PE Shielded UTP Cable.

Note: The Maximum cable length connecting GPS Master Clock to various Slave clocks is 4000ft.For cable length exceeding 4000ft., line amplifiers would be used to support additional cable.

GPS Master Clock Solution with Wired Slave Clocks and Redundant Master Clock

Deployed to display accurate and uniform time in all the clocks of an industrial premises, all the slave clocks needs to be synchronized to UTC. The UTC is obtained using the GPS Master Clock. All the slave clocks are connected to the master clock using PE Shielded UTP Cable.

For critical industrial application where downtime is unacceptable, a redundant clock and an auto Clock switcher unit is deployed to ensure minimal downtime

Note: The Maximum cable length connecting GPS Master Clock to various Slave clocks is 4000ft.For cable length exceeding 4000ft., line amplifiers would be used to support additional cable.

GPS Master Clock Solution with Wireless Slave Clocks

Deployed to display accurate and uniform time in all the clocks of an industrial premises, all the slave clocks needs to be synchronized to UTC. The UTC is obtained using the GPS Master Clock. All the slave clocks are connected to the master clock using License exempt radio devices operating in ISM band.

Note: GPS Master Clock Time code will be transmitted over the Radio to all the Slave clocks. Multiple Tx Radios can be deployed to achieve optimal communication coverage area.

GPS Master Clock with Wireless Slave Clocks and Redundant Clock

Deployed to display accurate and uniform time in all the clocks of an industrial premises, all the slave clocks needs to be synchronized to UTC. The UTC is obtained using the GPS Master Clock. All the slave clocks are connected to the master clock using License exempt radio devices operating in ISM band.

For critical industrial application where downtime is unacceptable, a redundant clock and an auto Clock switcher unit is deployed to ensure minimal downtime

Note: GPS Master Clock Time code will be transmitted over the Radio to all the Slave clocks. Multiple Tx Radios can be deployed to achieve optimal communication coverage area.
